Product description:
INQUIRY

hot dip galvanized dairy cow free stall provides rest place for cow, and regulates the rest position of each cow. It is customized according to different kinds of cow's shape, and made of hot-galvanized steel pipe. It adopts concrete casting fixed on site, and the cow neck rail with cow sitting apparatus regulates the cow lying on the right position on the bed. Good bedding will make the cow have less disease,mastitis, nipple damage.

cow free stall components are cattle lie bar, cow neck rail, matching the card and the bolt. In accordance with the specifications and different housing layout, can be divided into single bed and double bed.

Features of Cattle Free Stall
1. All the steel pipes for the horizontal rail adopt the internal and external hot-dip galvanizing process, and the coating penetrates into the pipe body, which is anti-corrosion, anti-acid, durable, and can be guaranteed not to rust for 20 years;
2. Cold-formed integral molding, the connection is fixed by bolts, the whole does not need welding, is not easy to rust and deform, and is durable;
3. The size is flexible, and the length and width are completely designed according to the age and body shape of the cow, which is convenient for lying down and entering and exiting without interfering with each other;
4. The shape and structure are designed according to bovine body bionics to ensure comfortable sleep for cows;

5. The unique design of the square avoids the bumps when the cows get up and down, and ensures the safety of cows.

The composition of cow free stall is mainly made by thickening the hot-dip galvanized pipe according to the specified size through the bending process. According to the cow stall used, it is divided into different specifications. Common ones are: 1950mm/2050mm/2150mm.

The installation distance of each cow stall is: between 1.1 meters and 1.2 meters.

Item	R-Shape Single Row Type	R-Shape Double Row Type
Component	stall, neck rail, chest rail, clamp, screw/bolt.
Animal Range	dry cow, lactating cow, young cow, growing cow, heifer, weaning cow.
Material	3mm hot dip galvanized pipe(Dia:61mmx55mm)
Cattle Spacing	(1.00m-1.20m)/cow	(1.00m-1.20m)/cow
Length(m)	2.00	4.00
Width(m)	1.00-1.20	1.00-1.20
Height(m)	1.0-1.35	1.0-1.35
Note: Free stall size(L,W,H) is customizable.
