Product description:
INQUIRY

Cattle Head Lock stall:
It is convenient for cows to stabilize, and can be flexibly opened and closed when cows bow their heads to feed. It is convenient for veterinarians or breeders to carry out routine physical examination, immunization, artificial insemination, pregnancy, treatment, dehorning, calving and other activities on cows, reducing labor intensity and improving work efficiency. .

The main components of Cattle Head Lock stall: movable rod, movable vertical pole, movable baffle, the bolt and the pin, etc. Cattle Head Lock stallaccording to its different specifications and models. The Cattle Head Lock stall can ensure the feeding of dairy cows and fix the cows, which is beneficial to epidemic prevention and breeding and treatment of cows.

Material: Hot Dip Galvanized steel pipe
Size: All sizes, or customized
Function & application: Positioning cow/cattle head and other function
Scope of application: Cow, cattle and other livestock
Surface treatment/finish: Hot Dip Galvanized
Main parts: Motion bar, Stand bar, Baffle, Clamp, Bolt & Axis Pin etc
Package: Standard export pallet. Packing as your requirement

Name	Specification	Galvanized layer	Weight(kg）
8 feet long	Three bits 0.75 meters/bit	500g/m2	67.66
8 feet long	Four bits 0.57 m/bit	500g/m2	70.55
10 feet long	Four bits 0.75 m/bit	500g/m2	86.65
10 feet long	Five bits 0.57 m/bit	500g/m2	87.57
12 feet long	Five bits 0.75m/bit	500g/m2	105.54
12 feet long	Six bits 0.57 m/bit	500g/m2	106.18
4.5 meters long	10 bits 0.403 m/bit	500g/m2	80.69
4.5 meters long	10 bits 0.403 m/bit	500g/m2	91.07
