The chain disc is made of pure nylon raw material injection molding, with strong abrasion resistance, high tensile strength and durability.

Chain material: 20Mn2
Chain diameter: 5.0mm/ 6.0mm
Chain breaking load: 3000kg
Material of disc: high-strength nylon injection molding
Diameter of disc: 36mm / 42mm / 45mm
The distance between disc: 70mm
Chain disc suit for feeding tube 60mm , 90mm, 102mm

advantages of chain :
1. This product adopts high-strength chain, which has large tensile force and strong toughness. After special heat treatment, the yield strength reaches 1.5-1.8 tons, and the breaking force is 3.2-3.5 tons.
Test data of this product:
1. Tensile resistance: 3.2-3.6T, which is 3 times that of ordinary chains.
2. The anti-dropping force of the injection molding part is 800 kg, which is 5 times that of the common plug-disc anti-dropping force.
