Product description

Evaporative cooling pad is a special paper honeycomb structure material, and its working principle is the natural physical phenomenon of "water evaporation to absorb heat". That is, water flows from top to bottom under the action of gravity to form a water film on the surface of the corrugated fiber of the cooling pad. When the fast flowing air passes through cooling pad, the water in the water film absorbs the heat in the air and evaporates to take away a large amount of heat reducing the temperature to achieve the purpose of cooling.

Performance characteristics

1) Corrugated paper with the spatial crossing linking technology, high absorbability, high water resistant, anti-mildew and long service life.
2) Large evaporation area, cooling efficiency as high as 80%.
3) The product absorbs water naturally, with fast speed of pervasion and lasting effectiveness. One drop of water can diffuse within 4~5 seconds. The natural absorption height is 60~70mm/5minutes, as 200mm/1.5 hours, having reached international standard .
4) The product does not contain phenol which is irritant to the skin and the like chemical products. It is safe, energy saving, environmental protective, economic and durable.
5) Aluminum Alloy, Galvanized Steel, 430 Stainless Steel is optional.

Technical Parameters

Cooling system: Water go through the pipe under the pressure of pump and enterthe paper, then forms water spray, when the dry and hot air go through the coolingpad under the pressure of fans, the heat in the air left by the cool water in thecooling pad, in this way, reach the cooling purposes.

Installation Diagram

Application :

Poultry and animal husbandry: chicken farm, pig farm, cattle farm.

Greenhouse and horticulture: vegetable storage, seed house, floral planting, straw plantation.

Industrial cooling: factory cooling and ventilation, industrial humidification, entertainment venues, pre-coolers, air handling units, etc.
